GuangZhou STS Lighting Equipment Co.,Ltd

Product Information

The new member of the four headed LED pattern light family - M SPOT30BAR, equipped with four 30W LED beads, is one of the indispensable products for professional stage. Configure 7 colors with white light and 7 patterns with white light to meet various scene requirements. Pattern jitter, color rainbow effect, built-in degree, and self walking effect. The manual focusing function makes the pattern effect more perfect, and the petite size greatly facilitates installation and transportation during use. LED light beads are energy-saving and environmentally friendly, suitable for various professional stage performances.

Parameters

※ HOUSING

◈ Plastic Housing

※ SOURCE

◈ 4pcs x 30W White LED

◈ 50,000 Hour Average LED Life

※ PHOTOMETRIC DATA

◈ 24,000 LUX @1M

※ EFFECTS

◈ Gobo Shaking, Color Changing, Manual Focusing

◈ Strobe/ Pulse: 1-10 times/S

◈ Dimming: 0-100% Linear Electronic

※ COLOR

◈ Color Wheel With 7 Diachronic Colors Plus Open

◈ Split Colors

※ GOBOS

◈ Gobo wheel with 7 static gobos plus open

※ CONTROL

◈ 3/5/9/11/17/21/30/38 DMX channel in optional◈ 4 Button Control Panel

◈ LED Menu Display

◈ 3pin DMX In/Out

※ POWER

◈ 100-240V AC, 50/60Hz

◈ 140W Power Consumption

※ PACKAGE

◈ Packing: 2 in 1

◈ Inner Package: Carton

◈ Outer Package: Carton or Flight Case

Optional accessories

Features

◈  4pcs x30w white led
◈  3/5/9/11/17/21/30/38 DMX channel in optional
◈  7 brilliant, dichroic colors plus white
◈  Rainbow effect with adjustable speed
◈  Gobo wheel with 7 static gobos plus open
◈  Electronic dimmer
◈  Strobe effect with adjustable speed
◈  Internal programs
◈  Sound-control via built-in microphone; sensitivity adjustable
◈  Manual focus
◈  Exact positioning via 16 bit PAN/TILT movement resolution
◈  Positioning within 540° PAN and 200° TILT
◈  DMX-controlled operation or stand-alone operation with Master/Slave function
◈  Control board with 4-digit LED display for adjusting the DMX-starting address, PAN/TILT Reverse, Program, Reset
◈  Switch-mode power supply for operation between 100 and 240 volts
◈  DMX control via every standard DMX controller
